TPM 2.0 Module SPI 12Pin with SLB9670 Windows 11 Upgrade for Gigabyte Z790 AORUS Xtreme X,Z790 AORUS Elite AX-W,Z790 AORUS Elite DDR4,Z790 AORUS Elite AX DDR4,Z790 AORUS Master

Compute Securely Bus Header KeyImportant Notes: 1. This product is only compatible with older motherboards such as Intel and AMD. It is not compatible with newer motherboard models featuring firmware TPM, all-in-one PCs, or laptops. 2. The minimum hardware requirements for upgrading to Windows 11 via TPM 2.0 are as follows: a 1 GHz or faster 64-bit processor (dual-core/multi-core), 4 GB of memory, 64 GB of storage space, firmware supporting UEFI Secure Boot and TPM 2.0, a DirectX 12-compatible graphics card, and a display with a resolution of 720p or higher. 3. This product has a 12-pin-1 connector. Please carefully check the pin positions in the image to ensure compatibility with your motherboard before purchasing. Compatible models: for Gigabyte Motherboard Z790 D Z790 D AX Z790 UD AX Z790 S DDR4 Z790 EAGLE Z790M AORUS ELITE AX ICE Z790 AORUS ELITE AX ICE Z790 AORUS ELITE X WIFI7 Z790 AORUS PRO X WIFI7 Z790 AORUS PRO X Z790 AORUS MASTER X Z790 AORUS ELITE X AX Z790 AORUS XTREME X Z790M AORUS ELITE Z790M AORUS ELITE AX Z790 AORUS ELITE AX-W Z790 AORUS ELITE DDR4 Z790 AORUS ELITE AX DDR4 Z790 AORUS MASTER Z790 AERO G Z790 GAMING X AX Z790 EAGLE AX How to select and install a security module: 1. Confirm whether the host has TPM 2.0 or if TPM 2.0 is enabled. 2. Click “Run,” enter: tpm.msc (Win+R keys), and check if the TPM version is ready. 3. If version 2.0 is displayed but not ready, you need to configure settings in the BIOS; consult the motherboard manufacturer's customer service. 4. Open the host and inspect the TPM pins on the motherboard. 5. When installing the module, ensure the chip-side faces inward, align with the pins, and insert fully to prevent loosening. (See image for direction) Product Performance Compatible with: GC-TPM2.0 SPI 2.0 Chipset: SLB9670 Interface: SPI PIN DEFINE: 12-pin Core Applications: 1: Seamless upgrade to Windows 11: Resolve TPM 2.0 verification issues and easily upgrade to the latest operating system. 2: Enhanced hardware-level security: Provides an independent secure encryption chip specifically designed for securely storing sensitive data (such as encryption keys, digital certificates, and login credentials), thereby enhancing overall system security. 3: Hardware encryption acceleration: Reduces CPU load by accelerating encryption operations via dedicated hardware, indirectly improving system response speed and enhancing the smooth operation of certain encryption-dependent applications (such as games and security software).

• TPM 2.0(12pin-1) ,GC-TPM2.0 SPI 2.0 Compatible with Gigabyte Z790 D、Z790 D AX、Z790 UD AX、Z790 S DDR4、Z790 EAGLE、Z790M AORUS ELITE AX ICE、Z790 AORUS ELITE AX ICE、Z790 AORUS ELITE X WIFI7、Z790 AORUS PRO X WIFI7、Z790 AORUS PRO X、Z790 AORUS MASTER X、Z790 AORUS ELITE X AX
• Chipset:SLB9670 , Compute Securely Bus Header Key Compatible with Gigabyte Z790 AORUS XTREME X、Z790 AORUS ELITE AX-W、Z790 AORUS ELITE DDR4、Z790 AORUS ELITE AX DDR4、Z790 AORUS MASTER、Z790 AERO G、Z790 GAMING X AX、Z790 EAGLE AX、Z790M AORUS ELITE、Z790M AORUS ELITE AX
• Precautions: This product is only applicable to older motherboards such as INTEL and AMD, and is not applicable to new motherboard models with firmware TPM, all-in-one computers, and laptops.
• Important: The minimum hardware requirements for upgrading to Windows 11 via TPM 2.0 are as follows: 1 GHz or faster 64-bit processor (dual-core/multi-core), 4 GB of memory, 64 GB of storage space, firmware that supports UEFI Secure Boot and TPM 2.0, DirectX 12-compatible graphics card, and a display with a resolution of 720p or higher.
• Purpose a: Resolve the TPM 2.0 verification issue when upgrading to Windows 11, enabling it to function as an independent encryption chip, providing secure storage for sensitive data, and enhancing security;
• Use b: Hardware encryption acceleration, such as improving game lag issues and other functions.
